Product Specifications

Part Number:51372
UPC Number:765809513723
Style:Spin-On Lube Filter
Service:Lube
Type:Full Flow
Media:Enhanced Cellulose
Height:3.836 (97)*
Outer Diameter Top:3.668 (93)*
Outer Diameter Bottom:Closed:
Thread Size:22X1.5 MM
By-Pass Valve Setting-PSI:22
Anti-Drain Back Valve:Yes
Beta Ratio:2/20=12/25
Burst Pressure-PSI:275
Max Flow Rate:11-13 GPM
Nominal Micron Rating:21
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 2.834 (72)*2.462 (63)*0.200 (5)*

Principle Application:

Principle Application:Ford/Lincoln/Mercury (91-21), Mazda (00-09), Cadillac STS-V, XLR-V (06-09) vin code "S" - for Duratech engine
