WA6505
WA6505

Air Filter
WA6505

About this item

WIX Premium Panel Air Filters contain more media than OES filters. The high-tear strength polyurethane seal survives extreme hot and cold temperature conditions, protecting engines for normal and severe driving conditions such as stop and go traffic, dirt roads, construction sites, short trips, and interstate travel.

  • A = 220 mm; B = 110 mm; C = 110 mm; D = 220 mm; H = 144 mm

GTIN code:

Product Details

A 220 mm
B 110 mm
C 110 mm
D 220 mm
H 144 mm

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
4.2 D (U-HZB) 1HZ - - - 01/90 → 10/03
4.2 D (HZB50_, HZB50) 1H-Z 4164 94 128 01/93 →
STD - - - 01/97 →
Model Type 4.2 D (U-HZB)
Filter Type
Engine Code 1HZ
ccm -
kW -
HP -
Year of manufacture 01/90 → 10/03
Model Type 4.2 D (HZB50_, HZB50)
Filter Type
Engine Code 1H-Z
ccm 4164
kW 94
HP 128
Year of manufacture 01/93 →
Model Type STD
Filter Type
Engine Code
ccm -
kW -
HP -
Year of manufacture 01/97 →

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
3.0 D / TD SW 4 2982 85 116 10/01 → 01/05
3.0 TD 1KZ-TE 2982 92 125 08/97 → 01/05
Model Type 3.0 D / TD SW 4
Filter Type
Engine Code
ccm 2982
kW 85
HP 116
Year of manufacture 10/01 → 01/05
Model Type 3.0 TD
Filter Type
Engine Code 1KZ-TE
ccm 2982
kW 92
HP 125
Year of manufacture 08/97 → 01/05

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
4.0 TD (HJ61) 12HT 3953 100 136 08/87 → 12/89
4.2 TD (HDJ80) 1HD-FT 4164 125 170 03/95 → 12/97
4.2 TD (HDJ100) 1HD-FTE 4164 150 204 01/98 → 07/03
4.2 TD (HZJ80) 1HD-T 4164 123 167 01/90 → 12/97
4.5 D-4D (J20) 1VD-FTV 4461 173 235 08/07 →
Model Type 4.0 TD (HJ61)
Filter Type
Engine Code 12HT
ccm 3953
kW 100
HP 136
Year of manufacture 08/87 → 12/89
Model Type 4.2 TD (HDJ80)
Filter Type
Engine Code 1HD-FT
ccm 4164
kW 125
HP 170
Year of manufacture 03/95 → 12/97
Model Type 4.2 TD (HDJ100)
Filter Type
Engine Code 1HD-FTE
ccm 4164
kW 150
HP 204
Year of manufacture 01/98 → 07/03
Model Type 4.2 TD (HZJ80)
Filter Type
Engine Code 1HD-T
ccm 4164
kW 123
HP 167
Year of manufacture 01/90 → 12/97
Model Type 4.5 D-4D (J20)
Filter Type
Engine Code 1VD-FTV
ccm 4461
kW 173
HP 235
Year of manufacture 08/07 →

  • 17801-66020
  • 17801-66030
  • 17801-66040
  • 17801-68020
  • 17801-60040
  • 17801-66010
  • 17801-60050
  • 17801-61030
  • 17801-68030
  • 17801-61020

No Data Available

SVHC declaration according to the regulation EC 1907/2006 concerning the Registration, Evaluation, Authorisation, and Restriction of Chemicals (REACH).



Product: WA6505

MANN+HUMMEL is well aware of REACH and meets all legal obligations under this regulation.

MANN+HUMMEL has established internal processes to ensure implementation and compliance with the REACH Regulation. Especially, we continuously work on the assessment of the presence of SVHC (Substances of Very High Concern).

We may inform you that according to the present level of information and best knowledge, this product does not contain any SVHC listed on the Candidate List in a concentration above 0,1% (w/w).

Last update: 2025-05-28 00:00:00
