Secondary Element
42668
New

About this item

Since 1939, WIX Filters has been making new things in the filter business. The company makes plenty of filters for cars, diesel engines, farms, and factories. WIX's product line includes oil, air, fuel, and hydraulic filters, among others, catering to diverse needs in automobiles, trucks, and off-road equipment. Their long-standing expertise ensures quality filtration solutions across various markets.

  • Height = 154.762 mm; Outside Diameter Top = 168.275 mm; Outside Diameter Bottom = 168.275 mm; Inside Diameter Top = 16.662 mm; Inside Diameter Bottom = 107.137 mm; Volume Flow Rate = 11,326.532 l/min; Media Type = Cellulose

GTIN code:

Product Details

No Data Available

Height 154.8 mm
Inside Diameter Bottom 107.1 mm
Inside Diameter Top 16.7 mm
Outside Diameter Bottom 168.3 mm
Outside Diameter Top 168.3 mm

Nominal flow rate air 179532.4
Operating temperature min. (°C) -17.777
Operating temperature max. (°C) -17.777
Filter with by-pass valve No
Filter with anti-drain valve No
Filter with anti-siphon valve No

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
4520
Secondary Element - 90 122 01/65 → 12/72
4620 Secondary Element 6404A - 100 136 01/71 → 12/72
Model Type 4520
Filter Type Secondary Element
Engine Code
ccm -
kW 90
HP 122
Year of manufacture 01/65 → 12/72
Model Type 4620
Filter Type Secondary Element
Engine Code 6404A
ccm -
kW 100
HP 136
Year of manufacture 01/71 → 12/72

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
6030
Secondary Element 6531D - 129 176 01/72 → 12/77
Model Type 6030
Filter Type Secondary Element
Engine Code 6531D
ccm -
kW 129
HP 176
Year of manufacture 01/72 → 12/77

Model Type Filter Type Engine Code ccm kW HP Year of manufacture
7020 Secondary Element 6404A - 107 146 01/71 → 12/75
Model Type 7020
Filter Type Secondary Element
Engine Code 6404A
ccm -
kW 107
HP 146
Year of manufacture 01/71 → 12/75

  • A-44186

  • AR61988

  • A-44186

No Data Available

SVHC declaration according to the regulation EC 1907/2006 concerning the Registration, Evaluation, Authorisation, and Restriction of Chemicals (REACH).



Product: 42668

MANN+HUMMEL is well aware of REACH and meets all legal obligations under this regulation.

MANN+HUMMEL has established internal processes to ensure implementation and compliance with the REACH Regulation. Especially, we continuously work on the assessment of the presence of SVHC (Substances of Very High Concern).

We may inform you that according to the present level of information and best knowledge, this product does not contain any SVHC listed on the Candidate List in a concentration above 0,1% (w/w).

Last update: 2026-03-23 00:00:00
