Hydraulic Transmission Filter
57088

About this item

WIX HD Automatic Transmission Filters use very good material for the job, including man-made stuff with wire, better paper, and wire mesh. WIX HD Transmission Filters ensure leak-resistant, long-lasting performance under all operating conditions.

  • Height = 102.108 mm; Outside Diameter Top = 85.344 mm; Nominal Micron Rating = 10 µm; Thread Size = 3/4-16; Beta Ratio = 2/20=8/18; Burst Pressure = 15.306 bar; Flow Type = Full flow; Min. Flow Rate = 34.068 l/min; Max. Flow Rate = 26.497 l/min; Media Typ

GTIN code:

Product Details

No Data Available

Height 102.1 mm
Outside Diameter Top 85.3 mm
Thread Size 3/4-16 mm

Max. Flow Rate (l/min) 26.497
Min. Flow Rate 34.068
Filter media material
Beta Ratio 2/20=8/18
Nominal Micron Rating 10
Burst pressure 15.306
Filter with by-pass valve No
Filter with anti-drain valve No
Filter with anti-siphon valve No

No Data Available

No Data Available

No Data Available

SVHC declaration according to the regulation EC 1907/2006 concerning the Registration, Evaluation, Authorisation, and Restriction of Chemicals (REACH).



Product: 57088

MANN+HUMMEL is well aware of REACH and meets all legal obligations under this regulation.

MANN+HUMMEL has established internal processes to ensure implementation and compliance with the REACH Regulation. Especially, we continuously work on the assessment of the presence of SVHC (Substances of Very High Concern).

We may inform you that according to the present level of information and best knowledge, this product does not contain any SVHC listed on the Candidate List in a concentration above 0,1% (w/w).

Last update: 2026-03-23 00:00:00
